Do you really install the hinge hinge? ? ?

The hinges and hinges of the relevant department standards are a kind of products, and the functions are becoming more and more abundant. The types of hinge hinges can be described as various types , but the change is still to ensure the safety and comfort of the products after installation. Today The hinge manufacturer came to the science of the hinge hinge device.

[Hinge device] hinge device method hinge device method

Hinge hinge device method

The process of the hinge device is relatively simple. After preparing the good thing, the position is positioned. The hinge is fixed and the device is basically completed. The netizens can also install it at home.

1, prepare things

Special equipment is prepared in front of the device, such as a tape measure/level ruler for measuring, a carpenter pencil for drawing a line, a carpenter hole/pistol drill for opening, a screwdriver for fixing, and the like.

2, draw line positioning

First use the device measuring board or carpenter pencil line to locate (the drilling margin is usually 5 mm), then use a pistol drill or a carpenter hole puncher to make a 35 mm hinge cup hole on the door panel. The drilling depth is generally 12 mm. ;

3, fixed hinge cup (hinge products)

Fix the hinge cup with the self-tapping screws in the hinge cup hole on the starter panel of the hinge sleeve;

4, fixed base

After the hinge is embedded in the cup hole of the door panel, the hinge is opened, then the side plate is inserted and aligned, and the base is fixed by a self-tapping screw;

5, debugging role

The end step, open and close the door test function.

The general hinges can be adjusted in six directions, aligned up and down, and the two doors are moderately centered. It is better to adjust the cabinet door. The clearance after closing the door is generally 2 mm.

Device attention

In order to make the hinge hinges strong and durable, in addition to the product's own texture, reasonable equipment is also very much needed. Let's take a look at the matters that are noticed during the hinge hinge of the device:

1. Pay attention to the orientation and quantity of the device.

In theory, the larger the two hinge distances, the stronger the bearing capacity. Of course, this also takes into account the reality. The home door leaf can be used with three hinges, and the general door can be used with two hinges.

It should be noted that the hinge cannot be installed at the corner joint of the door and window fan body, so that the device has a better benefit of 1/10 of the door and window fan body, and avoids the spread of the three equal parts, and can be used for the next two. Set to avoid the situation where the door leaf is tilted outward.

2, prevent falling fan

The falling fan means that the door and window device is bad, the upper space is gradually increased, and the lower space is gradually smaller, resulting in poor switch and falling in serious cases.

The reason for this situation may be that the hinges of too small specifications are selected, and the matching screws may not be used.

3, master the gap distance

The gap between the hinge and the door panel should be mastered, otherwise the appearance will be ugly, the gap of the door panel is normally 3-5MM, and the expansion joint should be left.

4, to ensure that the accessories match

Whether the hinge groove and the hinge height, width and thickness match. Whether the hinge and the screws and fasteners connected to it are matched. The joint method of the hinge should match the material of the frame and the fan. For example, the hinge used for the steel frame wooden door, the side that is connected with the steel frame is welded, and the side that is connected with the wooden door fan is fixed by wood screws.

5, the fan shaft should be the same vertical line

When installing the device, make sure that the hinges on the same fan are on the same vertical line to avoid the door and window sash.

Editor's summary: The process of the hinge hinge device is not messy, but the so-called details determine the victory or defeat, and look at the small hinges that are inconspicuous. In fact, there are also a lot of knowledge in the interior. The improper installation of the device will affect the comfort of the home. Therefore, the decoration user must pay special attention to the product's own texture and reasonable equipment.
